3 Series E91 320i (N43) TOUR

Page 1
background image

51 41 018

Replacing speaker trim on front left or right
door trim panel

Necessary preliminary tasks:

•

Remove speaker in door trim panel at front

Carefully release speaker trim (1) at catches (2) and remove in
outwards direction.

Note:

Catches (2) are held in position by installed speaker.

Installation:

Make sure catches (2) are in correct position. Speaker trim (1)
can only be installed in one position.

Installation:

Catches (1) must not be damaged or missing.

RA  Replacing speaker trim on front left or right door trim panel

BMW AG - TIS

24.01.2013  13:31

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 1 -
