3 Series E91 320i (N43) TOUR
52 13 405
Replacing backrest cover for left or right front
seat (normal / manual)
Special tools required:
•
52 0 050
Necessary preliminary tasks:
•
Remove front seat
•
Remove guide sleeves
Version with seat heating only:
Unfasten plug connection (1) and disconnect.
Disconnect cable straps.
Release wiring harness (2) from cable holders on seat
mechanism.
Important!
Feed the wiring harness carefully through the seat and
backrest mechanism as the edges of the frame can be sharp.
Detach backrest cover (1) from backrest frame.
