3 Series E91 320i (N43) TOUR
61 61 041
Replacing both windscreen wiper blades
Important!
Make sure the wiper arm does not contact the windscreen
without its wiper blade.
Fold wiper arm (3) away from windscreen.
Press lock (1) and remove cover cap (2) in direction of arrow.
Installation:
Make sure cover cap (2) is correctly seated.
Turn windscreen wiper blade (1) at an angle of 90
°
and remove
from windscreen wiper arm (2).
Installation:
Catches (1) and guide (2) of window cavity cover cap (6) must
not be damaged or missing.
RA Replacing both windscreen wiper blades
