3 Series E91 320i (N43) TOUR
00 00 M4 and M5 - maximum tightening torques acc. to BMW GS 90003-2
Type
Thread
Tightening specification
Measure
Scope of applicability of tightening
torques,
refer to excerpt from company
standard BMW GS 90003-2
Surface colour
/ (surface
coating)
M4 thread
yellow (ZN)
M4 8.8
3 Nm
silver (ZNS)
M4 8.8
2 Nm
yellow (ZN)
M4 10.9
4 Nm
silver (ZNS)
M4 10.9
3 Nm
yellow (ZN)
M4 12.9
5 Nm
M5 thread
yellow (ZN)
M5 8.8
6 Nm
silver (ZNS)
M5 8.8
5 Nm
yellow (ZN)
M5 10.9
8 Nm
silver (ZNS)
M5 10.9
7 Nm
yellow (ZN)
M5 12.9
10 Nm
silver (ZNS)
M5 12.9
8 Nm
AZD M4 and M5 - maximum tightening torques acc. to BMW GS 90003-2
BMW AG - TIS
24.01.2013 19:58
Issue status (12/2007) Valid only until next DVD is issued
