3 Series E91 320i (N43) TOUR
12 52 Plug connections, terminals, loose parts (N43)
Type
Thread
Tightening specification
Measure
1AZ Intake system duct
M6x16
7.5 Nm
2AZ Ignition coil ground to cyl. head
M5 nut
7.5 Nm
3AZ Pin for bracket to spring strut dome,
left
M6
3 Nm
4AZ Holder B+ line
7.5 Nm
5AZ Ground, electr. water pump
M8x16
19 Nm
6AZ Front duct to cyl. head
M6x16
8 Nm
7AZ Ground to ground point
M6 nut
8 Nm
AZD Plug connections, terminals, loose parts (N43)
