3 Series E91 320i (N43) TOUR
34 41 Parking Brake
Type
Thread
Tightening specification
Measure
1AZ Handbrake lever to body
E81, E82, E87,
E88, E90, E91,
E92, E93
21 Nm
2AZ Spring clip to wheel carrier
E81, E82, E87,
E88, E90, E91,
E92, E93
M6
8 Nm
3AZ Support Duo-Servo to wheel carrier,
rear
E81, E82, E87,
E88, E90, E91,
E92, E93
M8
15 Nm
4AZ Guide tube to body
E81, E82, E87,
E88, E90, E91,
E92, E93
M6
8 Nm
5AZ Bracket, centre console
E81, E82, E87,
E88, E90, E91,
E92, E93
M6
8 Nm
AZD Parking Brake
