3 Series E91 320i (N43) TOUR
41 52 Rear side doors
Type
Thread
Tightening specification
Measure
1AZ Hinge pin
E83
M10x56
10 Nm
E60 / E61 /
E70 / E71
M8 nut
27 Nm
E87 / E90 /
E91
M10x1.25
25 Nm
2AZ Door to door hinge
E83
M8 nut
18.5 Nm
E60 / E61
M8x25
24 Nm
E70 / E71
M8x28
20 Nm
E87 / E90 /
E91
M8 nut
20 Nm
3AZ Door hinge to body
E83
M10x35 10.9
56 Nm
E60 / E61 /
E70 / E71
M12x36 8.8
66 Nm
4AZ Door plug connection to body
E60 / E61 /
E70 / E83 /
E87 / E90 /
E91
M5x16
3 Nm
5AZ Crash reinforcement to inner door
panel
E70 / E71
M8x20
18.5 Nm
AZD Rear side doors
