Installation:
Lightly oil contact surfaces.
Fit gearwheel (1) for left counterbalance shaft in direction of arrow.
Note:
Shown with crankshaft removed for clearer illustration.
Important!
Risk of mixing up gearwheels.
Pay attention to inclination of tooth flanks.
Insert counterbalance shafts (1) in direction of arrow in crankcase
(2).
Note:
Shown with crankshaft removed for clearer illustration.
Important!
Do not drop counterbalance shafts into the bearings.
Insert special tool 64 1 020 through the gearwheel into the
counterbalance shaft.
Carefully insert counterbalance shaft (1) in gearwheel in direction
of arrow.
Position counterbalance shaft (1) in direction of arrow in
gearwheel (2).
Note:
Shown with crankshaft removed for clearer illustration.
