3 Series E92 320d (N47) COUPE
Remove exhaust camshaft.
Note:
It is not necessary to adjust the engine timing in order to remove
the exhaust camshaft.
Release bearing caps A1 to A5 by 1/2 a turn at a time, working
from the outside inwards.
Feed exhaust camshaft upwards to remove.
Oil all bearing points (1).
Check installation position of the roller cam followers (Risk of
damage!).
Install exhaust camshaft (1) marked with (A).
RA Replacing exhaust camshaft (N47, N47S)
