3 Series E92 320d (N47) COUPE
Release chain tensioner (1).
Tightening torque: 11 12 2AZ
.
Remove camshaft bolts (1) and detach camshaft sprocket.
Tightening torque: 11 31 1AZ
.
Position intake camshaft (E).
Installation:
Note installation position of roller cam follower.
Fit exhaust camshaft (A) in such a way that both marks are
aligned.
Note:
See illustration.
Tighten all bearing caps A1 to A5 working from the inside
outwards.
Tightening torque: 11 31 2AZ
.
RA Checking camshaft timing (N47, N47S)
