3 Series E92 320d (N47) COUPE
Fit special tool 21 5 030 on clutch slave cylinder (1).
Press piston rod (2) with aid of spindle completely into clutch
slave cylinder.
Connect bleeder unit to brake fluid expansion tank.
Important!
Check relevant Operating Instructions for each device.
Charging pressure should not exceed 2 bar.
Connect bleeder hose to bleed valve (1).
Hold clutch slave cylinder in illustrated position (refer to figure)
with special tool 21 5 030 .
Open bleeder valve (1).
If bubble-free brake fluid emerges, retract piston rod (2) of clutch
slave cylinder with aid of spindle a little and press in again.
If no air bubbles escape, close bleeder valve (1), otherwise
repeat procedure.
Important!
Do not under any circumstances remove special tool
21 5 030 from clutch slave cylinder when brake system is
pressurized.
Piston with push rod can jump out of clutch slave cylinder.
Switch off bleeder unit or remove from brake fluid expansion tank.
RA Bleeding clutch hydraulic system
