3 Series E92 320d (N47) COUPE
Release screws.
Remove transmission bearing block (1).
Tightening torque 24 71 6AZ
.
Grip output flange (1) with special tool 23 0 020 .
Release nut with special tool 24 2 380 .
Tightening torque: 24 13 2AZ
.
Installation:
Replace nut and secure with a mandrel (8 mm) by caulking.
Detach output flange from output shaft.
Remove spacer.
Attach special tool 24 2 353 to output shaft (1).
RA Replacing output flange shaft seal (GA6HP19Z)
