3 Series E92 320d (N47) COUPE
Note:
Following states can be selected on special tool 00 2 261 .
A) Vehicle unsecured
B) Vehicle secured (after special tool is lashed to lifting platform
arm)
Note:
The following procedure must always be carried out on the left
and right sides.
Insert special tool 00 2 261 into opening in side frame with 3/8"
extension and secure ratchet to body. To do so, turn lock through
90
°
up to stop.
Warning!
Danger to life!
Check stopping of special tool 00 2 261 on side frame,
correct attachment if necessary.
Lash special tool 00 2 261 with tensioning strap 00 2 262
crosswise (as pictured) to lifting platform arm.
Warning!
Danger to life!
Carry out tensile and visual inspection of tensioning strap
00 2 262 , correct position if necessary.
RA Mount securing fixture for vehicle on lifting platform
