3 Series E92 320d (N47) COUPE
Shown with luggage compartment trim panel removed:
Unlock plug connections (2) and disconnect.
Pull out retaining plates (3) in direction of arrow.
Remove amplifier (1) from holder (4).
Replacement:
Carry out programming/coding.
RA Removing and installing (replacing) amplifier (Top hi-fi system)
