3 Series E92 328i (N51) COUPE
11 37 010
Removing and installing/replacing
intermediate lever (N51)
Special tools required:
•
11 4 270
•
11 4 450
•
11 4 481
Important!
Aluminium screws/bolts must be replaced each time they are
released.
The end faces of aluminium screws/bolts are painted blue for
the purposes of reliable identification.
Jointing torque and angle of rotation must be observed
without fail (risk of damage).
Necessary preliminary tasks:
•
Remove cylinder head cover.
If necessary, set eccentric shaft (1) on twin surface to minimum
lift (2).
