3 Series E92 328xi (N51) COUPE
11 36 Variable Camshaft Control
Type
Thread
Tightening specification
Measure
1AZ VANOS with sensor wheel to inlet
and exhaust camshafts
N51
M10x94
Replace screw
Jointing torque
20 Nm
Torque angle
180
°
2AZ Non-return valve VANOS to cylinder
head
N51
M14 x 1.5
13 Nm
3AZ Solenoid valve holder to cylinder
head
N51
M6x12
8 Nm
AZD Variable Camshaft Control
BMW AG - TIS
04.02.2013 20:03
Issue status (12/2007) Valid only until next DVD is issued
