11 66 Vacuum pump

Type

Thread

Tightening specification

Measure

1AZ  Vacuum pump to crankcase

N51

M6x40

Flat mushroom head
screws 10.9

10 Nm

2AZ  Sprocket wheel to vacuum pump

N51

M10x30

Screw 12.9 washed and

oiled

66 Nm

AZD  Vacuum pump

BMW AG - TIS

04.02.2013  20:09

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 1 -
