3 Series E93 320i (N46T) CONVER
Insert balancing shaft oil pump unit (3) into adapter sleeves.
Replace screws (2).
Install and tighten down screws (2).
Tightening torque 11 27 1AZ .
Install and tighten down screws (1).
Tightening torque 11 27 2AZ
.
Using clamp (4), pull sprocket wheel (5) off oil pump shaft until it
is no longer secured on toothing.
Slide in special tool 11 5 140 under balancing shafts (1) at
ground contact faces (2) as far as they will go (3).
Balancing shafts (1) are now secured.
RA Removing and installing/replacing oil pump (N46T)
