3 Series E93 323i (N52K) CONVER
13 71 000
Removing and installing/replacing intake filter
housing (N52/ N52K/ N53)
Unlock plug (1) and remove.
Release clamp and detach air intake hose (2).
Unlock air intake hose (1) sideways and detach.
Release bolts.
Remove intake filter housing (2) towards top.
RA Removing and installing/replacing intake filter housing (N52/ N52K/ N53)
