3 Series E93 323i (N52K) CONVER
54 37 ...
Convertible top service positions
Special tools required:
•
54 0 170
Work step service position for convertible top:
Necessary preliminary tasks:
•
Partially remove roofliner for roof shell at rear
Move convertible top into position.
Move convertible top cover so that angle of hinges is approx. 100
°
.
Note:
Remove roof hinge bracket with a 2nd person helping.
Release screws (1) on roof hinge bracket (2).
Tilt roof shell forwards over centre of gravity.
RA Convertible top service positions
