3 Series E93 323i (N52K) CONVER
65 20 160
Removing and installing/replacing TV aerial
Necessary preliminary tasks:
•
Remove luggage compartment trim on left side panel
•
Remove rear bumper trim
Note:
The operation is described on the left side; proceed in the same
way for the right side.
Release screw (1) and remove antenna.
Unclip antenna lead (2) on both sides completely.
Installation:
Ensure correct lead routing.
RA Removing and installing/replacing TV aerial
