3 Series E93 323i (N52K) Engine Air Pump, Lines And Control Valves
11 72 Air pump, lines and control valves
Type
Thread
Tightening specification
Measure
1AZ Secondary air valve to cylinder head
N52K
M6
8 Nm
2AZ Secondary air pump to mounting
bracket/pump carrier
N52K
M6
8 Nm
3AZ Intake hose / intake line to body
N52K
M6
8 Nm
AZD Air pump, lines and control valves
