3 Series E93 325d (M57T2) CONVER
Attach crankpin to connecting rod.
Remove special tool 11 6 330 .
Apply light coat of oil to connecting-rod bearing shells.
Fit bearing caps so that pair numbers match up.
Installation:
Use new conrod bolts.
Tighten down connecting rod bolts with special tool 00 9 120 .
Installation:
Tightening torque 11 24 1AZ
.
The gasket thickness must be recalculated when work is carried
out on the crankshaft drive or pistons.
Measuring the piston clearance:
Fit dial gauge with measuring fixture special tool 00 2 530 on
cleaned engine block sealing surface and set under pretension to
zero.
RA Removing and installing/replacing all pistons (M57T2)
