3 Series E93 325d (M57T2) CONVER
54 37 ...
Gauging coupling fastener (after removing
and installing roof module)
Special tools required:
•
00 9 251
•
00 9 450
•
54 0 130
•
54 0 131
•
54 0 132
•
54 0 180
Important!
To prevent damaging the coupling fastener gauge, set the
gauge down only in the transportation crate or on the cross
beam.
The coupling fastener gauge is a highly sensitive measuring
instrument which reacts even to light impacts with distortion.
The coupling fastener gauge must be checked for
dimensional accuracy on a master gauge after being
subjected to impact or dropped.
Note:
The coupling fastener must be gauged after each removal and
installation of the roof module.
Necessary preliminary tasks:
•
Roof module must be installed
•
Align basic gauge
RA Gauging coupling fastener (after removing and installing roof module)
