3 Series E93 325i (N53) CONVER
54 37 ...
Gauging roof module brackets
Special tools required:
•
00 9 251
•
00 9 450
•
54 0 140
•
54 0 141
•
54 0 142
•
54 0 143
•
54 0 180
Important!
The roof module brackets are gauged and the screw
connection sealed at the factory.
Gauging of the brackets is only to be carried out after a repair
to the body.
It is necessary in the warranty period to consult the country-
specific hotline before opening the screw connection seal.
Necessary preliminary tasks:
•
Align basic gauge
Important!
Always install and remove roof module gauge with 2 helpers.
To prevent damaging the roof module gauge, set the gauge
down only in the transportation crate or on brackets.
The roof module gauge is a highly sensitive measuring
instrument which reacts even to light impacts with distortion.
The roof module gauge must be checked for dimensional
accuracy on a master gauge after being subjected to impact
or dropped.
RA Gauging roof module brackets
BMW AG - TIS
03.02.2013 20:37
Issue status (12/2007) Valid only until next DVD is issued
