5 Series E39 520d (M47) SAL
11 53 000
Removing and installing or replacing coolant
thermostat (M47)
Caution!
When working on the oil, coolant or fuel circuit, you must
protect the alternator against contamination.
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an alternator
malfunction.
Caution!
If the charge air hoses are not fitted without grease and dry,
this will result in supercharger failure.
Fit charge air hoses without grease and dry.
Remove EGR cooler,
refer to 11 71 100.
Note:
Thermostat for EGR cooler must not be removed.
Drain and dispose of coolant.
Installation:
Replace seal.
Tightening Torque,
refer to Technical Data 11 11 5AZ.
Fill cooling system, vent and check for leaks,
refer to 17 00 005.
RA Removing and installing or replacing coolant thermostat (M47)
