5 Series E39 520d (M47) TOUR
64 12 500
Removing and installing / replacing complete
heater (Thermo Top S)
Remove front left wheel.
Remove trim panel from front left wheelhouse.
Caution!
Allow engine to cool down.
Unfasten plug connection.
Close off supply and return hose as well as fuel hose with hose
clips. Release hose clips (1) and disconnect hoses. Release
screws (2) and remove heater.
RA Removing and installing / replacing complete heater (Thermo Top S)
