5 Series E39 520i (M52) TOUR
26 11 Propeller Shaft. complete E39 / M52 A5S360R/390R / AUT TOUR
Deflection torque of universal joints
Ncm
20...70
Deflection angle transmission/propeller shaft
-0
°
15`...+0
°
45`
Deflection angle of centre mount
-1
°
08`...-0
°
08`
Deflection angle propeller shaft/final drive
+1
°
35`...+2
°
35`
Explanation of deflection angle:
Propeller shaft bent upwards=
Deflection angle positive (+)
Propeller shaft bent downwards=
Deflection angle negative (-)
TD Propeller Shaft. complete E39 / M52 / A5S360R/390R / AUT / TOUR
