5 Series E39 525tds (M51) TOUR
32 41 Pump and Oil Supply
Type
Thread
Tightening specification
Measure
1AZ Power steering pump / bearing block
of power steering pump to crankcase
/ oil sump / oil filter unit carrier / A/C
compressor carrier
E39 / M5
Observe tightening
sequence
25 Nm
E36, E38, E39,
E46, E52, E53
Note shims, refer also to
Service Information Gr. 32
21 Nm
M47T2 /
M57TU /
M57T2
M6
8 Nm
N62 / N62TU /
N73
M8
Replace nuts
21 Nm
N52 / N52K /
N53
M10 x 33
Replace aluminium screws
Follow repair instruction.
Jointing torque
20 Nm
Torque angle
90
°
N54
M10
Follow repair instruction.
38 Nm
E60, E61, E63,
E64, E65, E66,
E67, E83, E85
/ S54, E86 /
S54
M8
21 Nm
2AZ Pump bracket on engine support
E38 / M60/1 /
M60/2 / M62,
E39 / M62
22 Nm
3AZ Hydraulic line connections to vane
pump/power steering pump and
steering gear/banjo bolts, steering
hydraulics
E38
Banjo bolt
M12
Replace sealing rings
33 Nm
E36, E39, E46,
E52
Banjo bolt
M14
Replace sealing rings
35 Nm
E38
Banjo bolt
M14
Replace sealing rings
39 Nm
AZD Pump and Oil Supply
