5 Series E39 540i (M62) SAL
Installation:
Layout of retaining elements:
(1)
Nut
(2)
Washer
(3)
Rubber mount
Installation:
Check seal, replace if necessary.
Coat outer and inner grooves and sealing face of cylinder
head cover all round with anti-friction rubber coating, e.g.
glycerine.
Press internal gasket into groove in cover without torsional
stress, starting at the four corner radii.
Installation:
Align outer gasket loosely on groove in cover. Secure gasket
in groove in cover, starting in the corner radii at the back (1)
and locate without torsional stress in the groove.
Installation:
Clean gasket residue from sealing surface.
Apply coat of Drei Bond 1209 (refer to BMW Parts
Service) to contact surfaces of joint.
RA Removing and installing/sealing both cylinder head covers (M62)
