5 Series E39 M5 (S62) SAL
11 36 030
Removing and installing, sealing/replacing
left VANOS adjustment unit (S62)
Special tools required:
•
11 7 130
•
12 6 050
•
12 6 410
•
12 6 411
Read fault memory and make a documentary record.
Caution!
When the engine is switched off, VANOS moves the
camshafts to a position which is advantageous to engine
starting.
Before the VANOS adjustment unit is removed, the camshafts
and the VANOS adjustment unit must be set with the
Diagnosis and Information System (DIS) to the assembly
position.
Procedure for setting VANOS to assembly position:
-
Connect DIS Tester
-
Start engine
-
Select Diagnosis
-
Service functions
-
VANOS: approach assembly position
-
Switch off engine
RA Removing and installing, sealing/replacing left VANOS adjustment unit (S62)
