5 Series E60 528i (N52K) SAL
23 12 513
Replacing radial seal for drive shaft (GS6-
17BG/DG)
Special tools required:
•
23 0 320
•
23 0 490
Important!
After completion of work, change final drive fluid.
Use only approved transmission oil.
Failure to comply with this instruction will result in serious
damage to the transmission.
Necessary preliminary tasks:
•
Remove guide tube
Note:
Two covered removal holes (1) are located on end face of
radial seal.
