5 Series E60 530Li (N52) SAL
> E65, E66
The navigation system is important for the equipment version "TV in front".
With the equipment variant "Television in front", the NAV control unit works as an RGB decoder:
The navigation system converts FBAS signals into RGB signals.
The navigation system is a control unit in the MOST network.
> E60, E61, E63, E64, E70, E71, E90, E91, E92, E93
The navigation system has been integrated in the Car Communication Computer (CCC). This means that there
is only a separate navigation system for certain national versions.
-
SG-FD: Rear display control unit
> E65, E66
The rear compartment controller control unit is only provided with option 603 "Rear monitor".
The SG-FD is installed beneath the rear display.
The SG-FD is a control unit on the K-CAN system
The SG-FD converts the image signal into the screen display on the rear display: e.g. RGB signals into LVDS
signals.
The SG-FD is actuated by the video module.
Signal path: VM -> RGB wire -> SG-FD -> LVDS data wire -> FD
-
SGM: Safety and gateway module
>
E65, E66
The safety and gateway module is the data interface between the K-CAN (K-CAN Periphery and K-
CAN SYSTEM), the diagnosis wire, byteflight and PT-CAN.
The control units are diagnosed via the SGM.
>
E60, E61, E63, E64
•
Until 09/2005: SGM
•
from 09/2005: Body gateway module (KGM)
-
VM: Video module
Depending on the national version concerned, either the hybrid video module or the video module 5 (VM5) is
fitted.
The video module is the central receiver unit for the picture signals from the TV aerials. In addition, the video
module is a selector switch for the video sources.
•
The video module is the master control unit for the television.
•
The video module edits the picture signals from the TV aerials and from the DVD drive or DVD changer.
The video module is a control unit in the MOST network.
[more ...]
>E83, E85, E86
[more ...]
The following components are controlled:
-
Monitors: Central Information Display or Control Display
>
E60, E61, E63, E64, E70, E71, E83, E85, E86, E90, E91, E92, E93: Central Information Display (CID)
>
E65, E66: Control display (CD)
-
FD: Rear display
> E65, E66, E70, E71
SBT Digital and analogue television E60, E61, E63, E64, E65, E66, E70, E71, E83, E85
