5 Series E60 M5 (S85) SAL
51 13 399
Replacing rear-end trim section
Special tools required:
•
00 9 318
Important!
The Instructions on component cementing with double-sided
adhesive tape serve as the basis for this repair instruction and
must be observed without fail.
Removed rear-end trim section must be disposed of in each
case. Reattachment with adhesive tape is not permitted.
Removing rear-end trim section:
Release nuts (1).
Carefully detach rear-end trim section (2) from rear lid with
special tool 00 9 318 and hot air blower.
Fitting rear-end trim section:
Attach two magnetic tapes (1) on left/right in each case at
distance (A) to rear lid.
A= approx. 30 mm
RA Replacing rear-end trim section
