5 Series E60 M5 (S85) SAL
52 17 ...
Replacing padding for front seat thigh
support (M5)
Note:
Plug connections and fan only with seat heating and/or air
conditioning optional extra(s).
If necessary, unlock plug connection (1) and disconnect.
Release screws (2).
Installation:
Insert screws (2) with Loctite.
Unhook seat cover (1) from marked area.
If necessary, feed plug out of carrier (2) for thigh support.
Installation:
Ensure correct cable routing.
Remove carrier (2) for thigh support.
If necessary, unlock plug connection (1) and disconnect.
Remove padding (3) from cover (2).
RA Replacing padding for front seat thigh support (M5)
