5 Series E61 520d (M47T2) TOUR
84 10 050
Removing and installing (replacing) USB hub
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove luggage compartment wheel arch trim on left.
Disconnect plug connection (1).
Release screws (2).
Remove USB hub (3).
RA Removing and installing (replacing) USB hub
