5 Series E61 523i (N52) TOUR

compatible with the customer's vehicle, use the currently valid compatibility matrix table to
check whether it can be adapted to the vehicle.
-
If no, the mobile phone cannot be made compatible with the vehicle electrical system
and there can be no settlement through warranty.
-
If yes, check with the customer whether the "EUR 99 solution" described in the
"Action" section of this Service Information bulletin should be carried out.
Carrying out an upgrade while adhering to the above-mentioned criteria
Model series: E60, E61, E63, E64, E65, E66 E87, E90, E91, E92, E93, E70:
-
Replacement of the telephone control unit (MULF, TCU) is not permitted.
-
Programming and encoding of the control units with the current Progman version.
-
Conversion via path - Perform "Mobile phone upgrade" conversion.
Model series: E46, E53, E83, E85, E86, R50, R52, R53
-
Replace telephone control units (ULF, TCU) with current hardware according to parts
listing.
-
If parts clearing for the affected control unit is active in your own market, follow the
parts clearing process.
Note:
If, on account of the measures plan in Progman, a repeat of programming and/or a
replacement of control units is stipulated, proceed as follows:
-
Print out measures plan.
-
In markets which require parts to be returned, send in the measures plan with
the parts which have to be returned.
-
In markets which do not require parts to be returned, store the measures plan
in the vehicle records.
-
Settle the claim under the temporary defect code listed below.
Parts:
Important:
When choosing the telephone control unit, check by referring to the Electronic Parts
Catalogue (ETK) whether the part number listed below for the telephone control unit
corresponds to the last modification status.
If necessary, the entry in the ETK is definitive.
Allocation of optional extra (SA) and telephone control unit:
Optional equipment
Associated telephone control unit
(option 633)
"Telematic Control Unit" (TCU)
(option 639) (US only)
"Telematic Control Unit US" (TCU US)
(option 644)
"Universal charging hands-free electronics" (ULF)
Part number of telephone control unit to be fitted:
Series
TCU
(new part)
TCU US
(replacement part)
ULF
(new part)
E46
84 10 9 132 712
84 10 9 132 711
84 10 9 145 007
E39
Not installed
Not installed
84 10 9 145 007
E53
84 10 9 132 712
84 10 9 132 711
84 10 9 145 007
SI Upgrade of bluetooth telephone system All
BMW AG - TIS
05.02.2013 00:52
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
