5 Series E61 535d (M57T2) TOUR
Release screws on heat shield (1).
Release hose clamp (1) from air duct (2).
Remove air duct (2) towards top.
Release nut (1) and pull bracket off stud.
Detach oil line (1).
Tightening torque 11 42 5AZ
.
Detach oil line (2).
Tightening torque 11 42 5AZ
.
Unfasten hose clip (3).
Release screw (4).
Release screws (5) and (6) from connecting pipe.
RA Removing and installing or replacing high-pressure exhaust turbocharger (small t
