6 Series 630i (N53) Coupe
13 54 250
Replacing air intake hose (N52)
Necessary preliminary tasks:
•
Switch off ignition
•
Remove upper section of intake filter housing
Release clamp (1).
Detach air-mass flow sensor (2) from throttle valve assembly.
RA Replacing air intake hose (N52)
BMW AG - TIS
17.01.2013 11:44
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
