6 Series 630i (N53) Coupe
Unscrew nut (1).
Pull out bolt (2) towards front.
Remove upper control arm.
Installation:
Note insertion direction of bolt.
Replace self-locking nut.
Tighten bolt connection in normal position.
Tightening torque 33 32 14AZ
.
Replacement:
Unclip holder on control arm.
After installation:
•
Perform chassis alignment check
RA Replacing one upper control arm
BMW AG - TIS
17.01.2013 15:02
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
