6 Series 630i (N53) Coupe
51 45 181
Removing and installing/replacing bottom
right trim for instrument panel
Release screws (1).
Feed out bottom right instrument panel trim (2) in direction of
arrow.
Disconnect plug connection of footwell light (3).
Remove bottom right instrument panel trim (2).
Installation:
Mounts (1) and guide (2) of bottom right instrument panel
trim (3) must not be damaged.
Replacement:
•
Remove footwell light (4).
RA Removing and installing/replacing bottom right trim for instrument panel
