6 Series 630i (N53) Coupe
61 31 195
Removing and installing (replacing) front
controller
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove knob for controller
•
Remove centre console
If necessary, disconnect plug connections.
Release screws (1).
Remove controller (2) in direction of arrow from storage
compartment (3).
Replacement:
Carry out vehicle programming/coding.
RA Removing and installing (replacing) front controller
BMW AG - TIS
17.01.2013 18:07
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
