6 Series 630i (N53) Coupe
11 31 Camshaft
Type
Thread
Tightening specification
Measure
1AZ Upper and lower bearing strip of
camshaft (steel screw 10.9)
N53
M7x70
Insert screws dry
Jointing torque
8 Nm
Torque angle
60
°
2AZ Chain drive module to cylinder head
N53
M6x35
9 Nm
3AZ Guide rail to crankcase
N53
M8
20 Nm
4AZ Guide rail to cylinder head
N53
M7
14 Nm
5AZ Chain tensioner to cylinder head
N53
M22 x 1.5
Replace sealing ring
55 Nm
6AZ Screw plug in cylinder head
N53
M18x1.5
25 Nm
AZD Camshaft
