6 Series M6 (S85) Coupe
Rotate crankshaft (1) in direction of arrow, risk of damage to
special tool 11 5 250 .
Remove piston with connecting rod and special tool 11 5 250 .
Depiction of function on cylinders 1-5.
Important!
Risk of damage to oil nozzle.
Clamp special tool 11 5 341 in a vice.
Note:
Piston and piston pin are optimized to each other.
There are two different inside diameters on the piston pin.
Screw matching special tool 11 5 342 into special tool
11 5 341 .
Secure piston (1) with conrod to special tool 11 5 341 .
Warning!
Protective goggles must be worn for the next work step.
RA Removing and installing/replacing all pistons (S85)
