6 Series M6 (S85) Coupe
11 28 010
Replacing alternator drive belt (S85)
Important!
Mark the direction of rotation of the drive belt if it is to be
reused.
Replace the drive belt if it is fouled with coolant or engine oil.
Necessary preliminary tasks:
•
Remove fan cowl with electric fan.
•
Remove drive belt for A/C system.
Press down tensioning device (2) with ratchet in direction of
arrow.
Remove drive belt (1).
Installation:
Observe direction of rotation if reusing the drive belt.
Ensure drive belt is in correct installation position.
Assemble engine.
RA Replacing alternator drive belt (S85)
BMW AG - TIS
19.01.2013 13:18
Issue status (12/2007) Valid only until next DVD is issued
