6 Series M6 (S85) Coupe
16 11 030
Removing and installing fuel tank
Important!
After installation of fuel tank/prior to first engine start-up:
•
Check ground connection at fuel filler neck to body for
continuity. If necessary, clean contact surface between
body and fuel filler pipe screw connection.
•
Fill fuel tank with min. 5 l fuel.
Necessary preliminary tasks:
•
Draw off fuel from fuel tank
•
Remove rear right wheel.
•
Remove rear right wheel arch trim
•
Remove complete propeller shaft
•
Remove handbrake Bowden cables from wheel carrier and
unclip from fuel tank
•
Remove right tension strut for rear axle
•
Partially detach rear left and right underbody panelling.
Slacken nut (1).
Unfasten hose clip (2).
Disconnect filler vent line (3) from fuel filler pipe.
Installation:
Tightening torque 16 12 11AZ
.
Seal nut with underseal again.
Replace hose clip.
Release screws and remove heat shield (1).
RA Removing and installing fuel tank
