Unclip cable (1).

Unclip vent lines (2).

Raise fan cowl (3) approx. 3 cm.

Fold in both retaining tabs in direction of arrow.

Remove fan cowl (3) towards top.

Clear DME fault memory.

RA  Removing and installing/replacing fan cowl with electric fan (S85)

BMW AG - TIS

19.01.2013  14:00

Issue status (12/2007) Valid only until next DVD is issued
