6 Series M6 (S85) Coupe
Detach output flange (1) with special tool 31 2 106 and 3-claw
extractor tool (2) from output shaft.
Drive a hole into radial shaft seal using a centre punch.
Important!
Do not use a drill as drillings may result in transmission
malfunction.
Screw special tool 23 0 490 into radial shaft seal (1).
Drive out radial shaft seal (1) with impact weight (2).
Installation:
Coat sealing lips of new radial seal with gear oil.
Drive in radial seal as far as it will go with special tool 23 4 110
and plastic hammer.
RA Replacing radial shaft seal for output flange (GS7S47BG)
