6 Series M6 (S85) Coupe
32 21 231
Replacing (removing and installing) left or
right tie rod
Special tools required:
•
32 3 160
Important!
The steering gear must be replaced if the polished surface of
the rack is damaged (e.g. by corrosion)!
Necessary preliminary tasks:
•
Remove tie rod end from swivel bearing
•
Remove gaiter from power steering gear and slide back
Important!
To avoid damage to rack and to suspension mounting, move
rack in as far as possible.
Unscrew tie rod with special tool 32 3 160 from rack of power
steering gear.
Installation:
Tightening torque 32 21 2AZ
.
RA Replacing (removing and installing) left or right tie rod
BMW AG - TIS
19.01.2013 14:51
Issue status (12/2007) Valid only until next DVD is issued
