6 Series M6 (S85) Coupe
32 41 009
Checking operation of power steering vane
pump (M model)
Special tools required:
•
32 4 000
Important!
Prior to this check, first check all hose connections, the vane
pump and the power steering gear for leaks.
Adhere to the utmost cleanliness. Do not allow any dirt to
enter the hydraulic system.
After installation:
•
Fill and bleed hydraulic system
•
Check pipe connections for leaks
Necessary preliminary tasks:
•
Draw off and dispose off hydraulic fluid from fluid reservoir
Observe country-specific waste-disposal regulations
•
Remove front wheel
•
Remove reinforcement plate
•
Remove steering gear cover at side
•
Disconnect pressure line from power steering gear and
expose up to engine
Connecting special tool:
Connect special tool 32 4 000 (refer to Notes on use) with new
sealing rings to vane pump and pressure line.
1.
Connection, pressure line (vane pump)
2.
Connection, power steering gear
